Q&A

Q1: Aluminum panels are often compared to extruded planks. Specifically, where do the MAP-12/16 fit within Maibec Architectural’s offering, and why are they an attractive option for budget-conscious projects?

A: This panel, entirely folded at our facility, stands out for its installation efficiency and custom manufacturing. Made from 5000 series aluminum with a thickness of 2 mm (0.080 in), it offers superior durability.

Its main advantage lies in its fast installation: with heights of 12 or 16 inches and a practical interlocking system, a single panel quickly covers a large surface area, significantly reducing labor costs. Additionally, although available in standard lengths, we can manufacture it to custom dimensions. This eliminates jobsite waste and optimizes the budget, while maintaining aluminum’s lightweight advantage over steel.



Q2: Does the fact that the panel is folded rather than extruded limit design choices?

A: On the contrary, folding allows great flexibility while maintaining a highly effective concealed fastening system. For refined finishes, a “closed ends” option is also available, giving the extremities a solid, architectural appearance, often sought after for corners or wall terminations. It’s a high-end aesthetic without the usual installation complexity.



Q3: From a modular standpoint, is it possible to combine the MAP-12 (12 in) and MAP-16 (16 in) on the same façade to create rhythm?

A: Absolutely. Both profiles share the same interlocking design. It is therefore possible to alternate 12-inch and 16-inch rows on the same elevation to break monotony and create a dynamic visual rhythm, without requiring any technical adaptation.



Q4: The product can be installed vertically or horizontally. Is it the same fastening system, or does it require different preparation?

A: It’s exactly the same concealed fastening system. The panels are designed to be installed in both orientations. During installation, it is important to respect expansion gaps. Aluminum is a metal that reacts to temperature changes; our system with slotted holes is designed to let the material “move” freely without creating stress on the structure.





Q5: A common concern with large aluminum panels is oil canning. With a 2 mm thickness, how does the MAP-12/16 perform against this phenomenon?

A: Oil canning is often caused by metal that is too thin or under stress. The MAP-12/16 uses highly rigid 5000 series aluminum with a thickness of 2 mm.

By comparison, this thickness, combined with the rigidity of the 5000 alloy, allows the panels to withstand higher wind loads without affecting their integrity, significantly minimizing the risk of waviness, even with dark colors compared to steel cladding (often 24 or 26 gauge). The result is a durable, flat aesthetic.



Q6: The product uses an electrostatic powder coating. Beyond aesthetics, what is the advantage of this finish compared to liquid paint in terms of longevity?

A: Although both types of finishes offer the same warranty and comply with AAMA 2604 and 2605 standards, the technology differs. Unlike liquid paints that contain solvents, powder coating is a process (VOC-free) that creates a highly resistant chemical bond after curing.

• Finishes: Ability to achieve textured and stone-effect finishes.
• Thickness: A film thickness nearly double that of liquid paint, providing enhanced protection.
• Eco-responsibility: Certified powders often have Environmental Product Declarations (EPD), contributing to LEED credits for your sustainable projects.
• Uniformity: Optimal edge coverage and consistent film thickness.

Our partners: IFS Coatings, Tiger and AkzoNobel.



Key Takeaways

The MAP-12 and 16 is the ideal meeting point between economy and performance. Thanks to its 2 mm aluminum (5000 series), it eliminates the risk of oil canning while reducing your installation costs through its fast installation. It’s the strategic choice for creating durable and aesthetic façades without compromising the budget.
